Jerry Can Liquid Filling Machine

Jerry Can Liquid Filling Machine
Jerry Can Liquid Filling Machine Jerry Can Liquid Filling Machine Jerry Can Liquid Filling Machine Jerry Can Liquid Filling Machine Jerry Can Liquid Filling Machine Jerry Can Liquid Filling Machine Jerry Can Liquid Filling Machine Jerry Can Liquid Filling Machine Jerry Can Liquid Filling Machine
Basic Information
Place of Origin: Shanghai, China
Brand Name: DAESUM
Minimum Order Quantity: 1
Price: CN¥139,860-699,300
Get Best Price Contact Now
Machinery Capacity: 400BPH, 200BPH, 600BPH Voltage: 380V 50Hz
Filling Accuracy: ±0.1-0.2fs Filling Speed: 200-360 Bottles/s
Filling Range: 18-40L Machine Material: Stainless Steel 304
Filling Nozzles: 2-6 Nozzles Weight: 5000 KG
Output Speed: 5-6 Min/Pallet Container Shape: Square/round Jerry Can
Container Material: Plastic Voltage Supply: 415/220, 1/3Phase, 50/60Hz
Filling Mode: Above Or Under Liquid Level With Fast&dribble Fill Can On Pallet: 4*4 Cans On Pallet (16 Cans/pallet)
Control System: PLC+ Touch Screen
Highlight:

Jerry Can filling machine with warranty

,

Small bottle liquid filling equipment

,

Liquid filling machine for jerry cans

Jerry Can Liquid Filling Machine
Jerry Can Filling Machine with 2/4 nozzles Model GZ-25CX
Product Application
Designed for free-flowing to viscous products, including chunky products. Fill volumes from 20L to 25L at high flow rates with accuracies up to ±0.2% depending on pail size and product type.
Technical Specifications
Product Compatibility Free flow to high viscosity
Output Speed 5-6 minutes per pallet (dependent on can size and product type)
Container Shape Square/round Jerry Can
Container Material Plastic
Container Size Standard (custom sizes available on request)
Voltage Supply 415/220, 1/3Phase, 50/60Hz
Filling Accuracy Class X (0.5) (0.2%)
Filling Mode Above or under liquid level with fast & dribble fill
Can on Pallet Configuration 4×4 cans on pallet (16 cans/pallet)
Key Features
  • Two (2) sets of SS304 Nozzles equipped
  • Quick-release, fast interchangeable lance for easy maintenance; SS316 straight pipe
  • METTLER TOLEDO Brand Weight Scaler with digital display
  • Heavy duty weighting platform mounted single load cell, overload protected
  • All parts in contact with liquid constructed from SS304 & PTFE seals
  • Spring assists to close filling nozzle in event of power failure
  • Stainless steel 304 enclosure with front viewing Perspex mounted hinge cover
  • IP55 class control cabinet housing weighing indicator and pneumatic components
  • Movable nozzle design with auto movement in front/back and left/right directions
  • Auto jerry can hole tracking and one-step operation without operator involvement
Control System
  • Germany Siemens/Japan Omron PLC Control System
  • Manual/Net/Gross Filling with auto two-stage fast/dribble fill
Optional Items & Accessory Equipment
  • Digital Touch Screen Panel with System Integration
  • PLC to DCS synchronization and simulation
  • Storage tank with level controller
  • Available to suit Hazardous Environments with Ex-proof system
  • Nozzle diving system for foamy products
Customized configurations according to customer requirements are also available.
Call/email now for a quick response to your application questions.
